产品型号：M系列 原产地：台湾 品牌：TPC 产品说明： 1.检出方式：扩散反射／镜片反射／对照型 2.感应距离：扩散反射（10 or 40 cm）／镜片反射（3 m）／ 对照型（10 or 20 m） 3.输出方式：NPN NO/NC，PNP NO/NC 4.工作电压：DC10-30V 5.电线材质：PVC耐油电线 6.保护等级：IP66 7.防水性佳 8.NO/NC可切换 扩散反射:
鏡片反射型号 | 工作电压 | 感应距离 | 应差距离 | 输出方式 | 消耗电流 | 负载电流 | 残留电压 | 反应频率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
MDD-10N | 10-30V DC | 10 cm | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | Approx:163g |
MDD-10P | 10-30V DC | 10 cm | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | |
MDD-40N | 10-30V DC | 40 cm | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | |
MDD-40P | 10-30V DC | 40 cm | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
镜片反射:
型号 | 工作电压 | 感应距离 | 应差距离 | 输出方式 | 消耗电流 | 负载电流 | 残留电压 | 反应频率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
MRD-300N | 10-30V DC | 3M | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | 175g |
MRD-300P | 10-30V DC | 3M | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
对照型:
型号 | 工作电压 | 感应距离 | 应差距离 | 输出方式 | 消耗电流 | 负载电流 | 残留电压 | 反应频率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
MTD-1000N | 10-30V DC | 10 cm | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | Approx:304g |
MTD-1000P | 10-30V DC | 10 cm | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | |
MTD-2000N | 10-30V DC | 20 cm | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | |
MTD-2000P | 10-30V DC | 20 cm | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
