产品型号：BDD系列 原产地：台湾 品牌：TPC 产品说明： 1.检出方式：限定距离反射 2.感应距离：2，3，5 cm 3.输出方式：NPN NO/NC 4.工作电压：DC10-30V 5.电线材质：PVC耐油电线 6.保护等级：IP66 7.防水性佳
型号 | 工作电压 | 感应距离 | 应差距离 | 输出方式 | 消耗电流 | 负载电流 | 残留电压 | 反应频率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
BDD-02N | 10-30V DC | 2cm | ±10% | NPN NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | Approx:92g |
BDD-02P | 10-30V DC | 2cm | ±10% | PNP NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-03N | 10-30V DC | 3 cm | ±10% | NPN NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-03P | 10-30V DC | 3 cm | ±10% | PNP NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-05N | 10-30V DC | 5 cm | ±10% | NPN NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. | |
BDD-05P | 10-30V DC | 5 cm | ±10% | PNP NO/NC | 20mA Max. | 250mA Max. | 1V Max. | 2ms Max. |
