产品型号：X系列 原产地：台湾 品牌：TPC 产品说明： 1.检出方式：扩散反射／镜片反射／对照型 2.感应距离：扩散反射（70 cm）／镜片反射（4 m）／ 对照型（10 m） 3.输出方式：NPN NO/NC,PNP NO/NC 4.工作电压：DC10-30V 5.电线材质：PVC耐油电线 6.保护等级：IP66 7.防水性佳 扩散反射:
型号 | 工作电压 | 感应距离 | 应差距离 | 输出方式 | 消耗电流 | 负载电流 | 残留电压 | 反应频率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
XDD-70N | 10-30V DC | 70cm | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | 90g |
XDD-70P | 10-30V DC | 70cm | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
镜片反射:
型号 | 工作电压 | 感应距离 | 应差距离 | 输出方式 | 消耗电流 | 负载电流 | 残留电压 | 反应频率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
XRD-400N | 10-30V DC | 4M | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | 100g |
XRD-400P | 10-30V DC | 4M | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
对照型;
型号 | 工作电压 | 感应距离 | 应差距离 | 输出方式 | 消耗电流 | 负载电流 | 残留电压 | 反应频率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
XTD-1000N | 10-30V DC | 10M | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | 165g |
XTD-1000P | 10-30V DC | 10M | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
